Key Information

4 MPPTs, suitable for residential rooftop installations with multiple array orientations
Supports Unbalanced and Half-Wave Loads on the Grid Port and on the Backup Port
Compatible with multiple brands of battery models giving customers multiple battery options
Supports up to 10 units in parallel on Grid and Backup. Suitable for small to medium level commercial energy storage systems
Supports pure off grid applications with generator communication support
Multiple working modes to meet different use case scenarios
Controllable and Upgadeable via the SolisCloud App to avoide site visits
Up to 16A of MPPT current input to support 182mm/210mm solar panels
Supports 1.6 DC:AC ratio to connect more PV capacity to the energy storage system
Up to 50A/10kW max charge/discharge rating with industry highest level 10kW of backup loads support capability
UPS level switching time (<10ms) supporting critical loads all the time
High PV charge efficiency to prevent excess PV loss
Safety protection with integrated AFCI function, which actively detects arc faults in the PV Array
Natural convection design without external fans
The inverter is supplied including the S2-WL-ST data logger stick (WiFi & LAN) and a 3PH meter from Eastron
