GSE IN ROOF XXL Frame Portrait DPO - 2030/1135 (Half Frame)

The GSE IN ROOF XXL Frame Portrait DPO 2030/1135 is the largest half-frame tray in the GSE in-roof integration range, purpose-built for safe and simple in-roof integration of 500W+ PV modules in portrait orientation. Accepting modules from 1990 to 2180 mm in height and 991 to 1305 mm in width, this XXL frame addresses the growing demand for higher-wattage panels with larger surface areas. This listing is for one half frame only; two halves are required per module.

Key Technical Details

• Product: GSE IN ROOF XXL Frame Portrait DPO - 2030/1135 (Half Frame)
• Part Code: GSE-FRAME-DPO-2030-1135
• Manufacturer Reference: ART105792
• Nominal frame size: 2030 x 1135 mm
• PV module height tolerance: 1990 - 2180 mm
• PV module width tolerance: 991 - 1305 mm
• Compatible module surface area: Approximately 2.5 m²
• Compatible module weight: Approximately 30 kg
• Weight: 3.3 kg (per half frame)
• Mounting category: In-roof integration
• Array orientation: Portrait

Key Features

• Designed specifically for 500W+ PV modules, accommodating the latest generation of high-wattage panels with heights from 1990 to 2180 mm and widths from 991 to 1305 mm
• Builds on the proven design and installation methodology of the earlier Half-Frame H1650 and H1840 models, which have been in deployment for over a year
• Tested by recognised European laboratories to verify the structural strength and long-term durability of the installation under load
• Interlocking two-part tray design assembles to form a complete in-roof mounting platform per module
• Wide module width tolerance range of 991 to 1305 mm provides compatibility across a broad selection of current and emerging high-wattage panel formats
• Compatible with a comprehensive range of roof coverings including curved tiles, interlocking tiles, flat tiles, slates, metal, zinc, and trapezoidal profiles

Installation Notes

• This product is one half of a complete frame. Two half frames must be ordered per PV module in the array
• Due to the increased surface area (approximately 2.5 m²) and weight (approximately 30 kg) of modules compatible with this XXL frame, GSE recommends doubling the number of mid clamps and end clamps when securing modules to ensure mechanical stability
• Module sizes continue to evolve. Always use the GSE configurator tool and tolerance table to verify the correct frame size for the specific PV module being installed before ordering
• Fix half-frame trays to roof battens in accordance with the GSE batten plan for the XXL frame size
• Complete the array perimeter using GSE lateral flashings, top flashings, corner pieces, and pre-compressed foam sealant to achieve a fully weathertight installation
• Must be used exclusively with GSE in-roof system components to maintain full system compatibility and manufacturer warranty conditions

Certifications and Compliance

• Tested by recognised European laboratories for structural strength and installation durability
• MCS certified (MCS V11.2) for use within Microgeneration Certification Scheme registered installations

About GSE

GSE Integration develops in-roof photovoltaic integration systems as part of the SVH Energie group, continuously expanding their frame range to keep pace with the rapid growth in PV module dimensions and power outputs. The XXL DPO frame represents the latest evolution in this programme, extending the GSE IN ROOF system's compatibility to the 500W+ module class. With over 60% of the residential in-roof PV market in France and a growing UK presence, GSE provides professional installers with a well-established and laboratory-tested integration platform.
