GSE IN ROOF Frame Portrait DPO - 1840/1135 (Half Frame)
The GSE IN ROOF Frame Portrait DPO 1840/1135 is a half-frame tray engineered for larger, higher-wattage PV modules within the GSE in-roof integration system. Part of the 2022 half-frame design range, this tray accommodates portrait-oriented panels up to 1840 x 1135 mm, including larger format modules such as Eurener 480W and 500W panels. This listing is for one half frame only; two halves are required per module.
Key Technical Details
- Product: GSE IN ROOF Frame Portrait DPO - 1840/1135 (Half Frame)
- Part Code: GSE-FRAME-DPO-1840-1135
- Manufacturer Reference: ART105211
- Nominal frame size: 1840 x 1135 mm
- Weight: 3 kg (per half frame)
- System weight: 2-3 kg/m²
- Material: 100% recyclable
- Mounting category: In-roof integration
- Array orientation: Portrait
Key Features
- Sized to support larger format PV modules up to 1840 x 1135 mm in portrait orientation, catering for the trend toward higher-wattage panels from manufacturers such as Eurener (480W and 500W models)
- Part of the 2022 half-frame DPO range, developed to keep pace with the expanding dimensions and power outputs of modern PV modules
- Interlocking two-part tray design assembles to create a complete in-roof mounting platform per module
- Lightweight system at 2-3 kg/m², adding minimal structural load to the roof
- Manufactured from 100% recyclable materials
- Compatible with a comprehensive range of roof coverings including curved tiles, interlocking tiles, flat tiles, slates, metal, zinc, and trapezoidal profiles
- Suitable for new build and retrofit installations
System Capabilities
- The GSE IN ROOF system enables full in-roof PV module integration across virtually every common roof covering type, replacing tiles within the array footprint with flush-mounted solar modules
- Interlocking plastic trays form a continuous, weathertight mounting plane across the array area
- Trays are fixed to roof battens, surrounding tiles fit up to the perimeter flashing, and PV modules are hooked onto the assembled trays before being secured with GSE module clamps
- The system assembles quickly using a straightforward tray-interlock, hook, and clamp sequence
Installation Notes
- This product is one half of a complete frame. Two half frames must be ordered per PV module in the array
- Module sizes are continually evolving. Always use the GSE configurator tool and tolerance table to verify the correct frame size for the specific PV module being installed before ordering
- The DPO frame range should be specified using GSE's own configurator, accessible via the GSE product documentation
- Fix half-frame trays to roof battens in accordance with the GSE batten plan. Installation manuals are available for both 50mm and 100mm batten configurations
- Complete the array perimeter using GSE lateral flashings, top flashings, corner pieces, and pre-compressed foam sealant to achieve a fully weathertight installation
- Secure PV modules to the assembled trays using GSE mid clamps and end clamps of the appropriate height variant
- Must be used exclusively with GSE in-roof system components to maintain full system compatibility and manufacturer warranty conditions
Certifications and Compliance
- MCS certified (MCS V11.2) for use within Microgeneration Certification Scheme registered installations
About GSE
GSE Integration operates as a dedicated in-roof photovoltaic integration specialist within the SVH Energie group, bringing over a decade of development focused on innovation, competitiveness, and safety. The 2022 DPO half-frame range reflects GSE's ongoing commitment to keeping their system compatible with the latest module sizes entering the market. The GSE IN ROOF system commands over 60% of the residential in-roof PV market in France and continues to expand its footprint among professional installers in the UK.
