GSE IN ROOF Frame Portrait DPO - 1650/1100 (Half Frame)
The GSE IN ROOF Frame Portrait DPO 1650/1100 is a half-frame tray forming part of the structural foundation of the GSE in-roof photovoltaic integration system. Designed to accommodate portrait-oriented PV modules with dimensions up to 1650 x 1100 mm, this interlocking plastic tray is fixed directly to roof battens and provides the mounting platform onto which solar modules are hooked and clamped into place. This listing is for one half frame only; two halves are required per module.
Key Technical Details
- Product: GSE IN ROOF Frame Portrait DPO - 1650/1100 (Half Frame)
- Part Code: GSE-FRAME-DPO-1650-1100
- Manufacturer Reference: ART105155
- Module size compatibility: Up to 1650 x 1100 mm (portrait orientation)
- Weight: 3 kg (per half frame)
- System weight: 2-3 kg/m²
- Material: 100% recyclable
- Mounting category: In-roof integration
- Array orientation: Portrait
Key Features
- Interlocking half-frame tray design allows two physical halves to be assembled per module, creating a complete mounting platform within the roof plane
- Compatible with a wide range of roof coverings including curved tiles, interlocking tiles, flat tiles, slates, metal, zinc, and trapezoidal profiles
- Suitable for both new build and retrofit installations, providing flexibility across residential and commercial roofing projects
- Lightweight system at 2-3 kg/m², minimising additional structural load on the roof
- Manufactured from 100% recyclable materials
- Compatible with a range of standard PV module sizes within the 1650 x 1100 mm envelope. Refer to the GSE tolerance table to confirm frame compatibility with the specific module being installed
System Capabilities
- The GSE IN ROOF system enables full in-roof module integration on virtually every common roof covering type, replacing tiles within the array footprint with flush-mounted PV modules
- Plastic trays interlock to form a continuous, weathertight mounting plane across the array area
- Trays are fixed to standard roof battens, with surrounding roof tiles fitting up to the perimeter flashing
- PV modules hook onto the assembled trays and are secured using GSE module clamps
- The system supports single-module and multi-module array configurations in portrait orientation
Installation Notes
- This product is one half of a complete frame. Two half frames must be ordered per PV module in the array
- Module sizes vary between manufacturers and product ranges. Always use the GSE design tools and tolerance table to verify the correct frame size for the specific PV module being installed before ordering
- Fix half-frame trays to roof battens following the GSE batten plan for the selected frame size and roof type
- Installation manuals are available for both 50mm and 100mm batten configurations
- Complete the array perimeter using GSE lateral flashings, top flashings, corner pieces, and pre-compressed foam sealant to achieve a fully weathertight installation
- Secure PV modules to the assembled trays using GSE mid clamps and end clamps of the appropriate height variant
- Must be used exclusively with GSE in-roof system components to maintain full system compatibility and manufacturer warranty conditions
Certifications and Compliance
- MCS certified (MCS V11.2) for use within Microgeneration Certification Scheme registered installations
About GSE
GSE Integration develops in-roof photovoltaic integration systems as part of the SVH Energie group, with more than a decade of experience delivering innovative, competitive, and safety-focused mounting solutions. The GSE IN ROOF system has captured over 60% of the residential in-roof PV installation market in France and now serves professional installers across the UK with a comprehensive and proven in-roof integration platform.
